Troemner 7406-F1W 20 kg-1 g Weight Set, NVLAP Accredited Certificate, OIML Class F1
Troemner OIML Class F1 weights are typically used for calibrating high-precision top loading balances with a readability as low as 0.01 g to 0.001 g.
Supplied in handcrafted wood case. Includes a compartment for a polycarbonate case which holds weights 500 g and below. 1 kg and 2 kg weights are held in individual polycarbonate cases inside a felt-lined cutout. For weights 5 kg and larger, a felt-lined compartment for each weight exists within the wood case.
Weight Kit Contents
20 kg, 10 kg, 5 kg, (2) 2 kg, 1 kg, 500 g, (2) 200 g, 100 g, 50 g, (2) 20 g, 10 g, 5 g, (2) 2 g, 1 g
Certificate Details
Troemner's NVLAP Accredited Certificate provides compliance in both measurement process and data reported to the customer to meet a variety of standards including NVLAP Handbook 150-2, ISO/IEC 9000, ISO/IEC 17025, FDA, GMP. GLP, DOD, ANSI/NCSL Z540-1 and nuclear requirements. Troemner's NVLAP Laboratory Code is 105013-0. The NIST administered National Voluntary Laboratory Accreditation Program (NVLAP) approves, through periodic audits, all processing and weighing procedures, as well as certificate format and content. Calibration procedures vary by tolerance class requested. For example, for higher accuracy classes such as Troemner UltraClass Series, ANSI/ASTM E617 Class 000, 00, 0 and 1, OIML R 111 Class E0, E1, E2 and F1, Troemner performs a multiple weighing procedure utilizing standards to determine the mass of a customer's weight.
- Class:
- OIML Class F1
- Weight Range:
- 20 kg-1 g
- Number of Weights:
- 18
- Total Weight:
- 40 kg
- Style Description:
- Cylindrical with handling knob
- Dimensions:
- 24.6" x 19.7" x 11.7"
- Material:
- Weights above 1kg are 316 Stainless Steel, Weights 1kg and below are Troemner Alloy 8
- Certificate:
- NVLAP Accredited Certificate
- Manufacturer:
- Troemner
- Manufacturer Part Number:
- 7406-F1W
