Totalcomp TP-FLS-75 Single Point Load Cell, 75 lb

MSRP: $635.25
$571.73
(Save $63.52)
Part #:
4573
Availability:
Typically ships in 1-2 days

Totalcomp TP-FLS series single point load cells are constructed of stainless steel and are backed by an IP67 rating. Totalcomp TP-FLS series load cells also include a 10 ft cable and a safe overload rating of up to 200% capacity.

Features

  • Stainless steel construction
  • 1 mV/V output
  • IP67 rating
  • Load cell cable length 10 ft
  • Safe overload up to 200% capacity

Interchange

  • Weigh-Tronix FLS

Documentation

Totalcomp TP-FLS Datasheet

1 year limited manufacturer's warranty
Capacity:
75 lb
Construction:
Stainless steel
Cable Color Code:
Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal, Bare = Shield
Rated Excitation:
10 VDC (maximum of 15 V)
Full Scale Output:
1 mV/V
Input Resistance:
400 ohms
Output Resistance:
350 ohms
IP Rating:
IP67
Combined Error:
0.03 % full scale
Nonlinearity:
0.02 % full scale
Hysteresis:
0.02 % full scale
Zero Balance:
1 % full scale
Safe Overload:
200 % full scale
Ultimate Overload:
300 % full scale
Compensated Range:
-10C to 40C
Safe Temperature Range:
-20C to 60C
Cable Length:
10 ft
Manufacturer:
Totalcomp
Model:
TP-FLS-75
Part Number:
4573
