Totalcomp T752 series canister load cells are designed for heavy capacity industrial applications. They are constructed with stainless steel casings and carry an IP67 rating, which allows them to perform in demanding conditions. Mounting hardware is not included and must be ordered separately.
Features
- Stainless steel
- 2 mV/V output
- IP67 rating
- Load cell cable length 50 ft
- Safe overload up to 150% capacity
- REQUIRES Cap (PN 5409), Pin (PN 5410), and base (PN 5411), order separately
Interchange
- Toledo Model 752
Documentation
1 year limited manufacturer's warranty
- Capacity:
- 100,000 lb
- Construction:
- Stainless steel
- Cable Color Code:
- White = + Excitation, Blue = - Excitation, Yellow = + Sense, Red = - Sense, Green = + Signal, Black = - Signal, Bare = Shield
- Rated Excitation:
- 10 VDC (maximum of 15 V)
- Full Scale Output:
- 2 mV/V
- Input Resistance:
- 820 ohms
- Output Resistance:
- 775 ohms
- IP Rating:
- IP67
- Seal Type:
- Environmentally sealed
- Combined Error:
- +/- 0.03 % full scale
- Nonlinearity:
- +/- 0.05 % full scale
- Hysteresis:
- +/- 0.03 % full scale
- Zero Balance:
- +/- 1.00 % full scale
- Safe Overload:
- 150 % full scale
- Ultimate Overload:
- 300 % full scale
- Safe Temperature Range:
- -10C to 40C
- Operating Temperature Range:
- -20C to 60C
- Cable Length:
- 50 ft
- Manufacturer:
- Totalcomp
- Model:
- T752-100K-SS
- Part Number:
- 1148
