Rice Lake RL1805SS Series Stainless Steel Weigh Module Kit, (3) 4000 lb Capacity Modules
Rice Lake RL1800SS Series weigh module kits are best suited for light to medium weight tanks and hoppers in harsh environments. This Rice Lake module kit includes three RL32018S-4Klb load cells, one JB4SS stainless steel signal trim j-box, three RL1805SS stainless steel compression mounts, and 25 feet of hostile environment EL147HE SURVIVOR® load cell cable. The RL32018S series load cells are environmentally sealed with an IP66 rating, are constructed of stainless steel, and have a 20 ft long load cell cable.
Features
- Light to medium capacity tank and hopper weighing applications
- 12,000 lb combined capacity rating
- Recommended scale capacity 6000 to 8000 lb
- Recommended readability 2 lb
- Three 4000 lb rated load cells / modules
- Stainless steel load cells
- IP66 rated load cells
- Load cell cable length 20 ft
- Load cell safe overload up to 150% capacity
- Three stainless steel RL1805SS compression mounts
- 25 ft hostile environment EL147HE Survivor load cell cable for connecting J-box and indicator
- Signal trim stainless steel junction box
- Single ended beam design
- Simple installation
- 2 year limited warranty
- NTEP Certified 1:5,000 Class III Multiple Cell
Documentation
Rice Lake RL32018S Datasheet Rice Lake RL1800 Datasheet Rice Lake RL1800 Installation Guide
2 year limited manufacturer's warranty
- Manufacturer:
- Rice Lake Weighing Systems
- Model:
- RL1805SS Weigh Modules (3) 4000 lb
- NTEP:
- Yes
- Class:
- III
- Combined Capacity Rating:
- 12,000 lb
- Recommended Capacity of Scale:
- 6000 lb to 8000 lb
- Individual Load Cell Capacity Rating:
- 4000 lb
- Load Cell Safe Overload:
- 150% capacity
- Load Cell Rated Excitation:
- 5-10 V AC/DC (15 V max)
- Load Cell Output:
- 3 mV/V
- Cell Output Resistance:
- 350 (± 3) ohm
- Cell Input Resistance:
- 400 (± 20) ohm
- Seal Type:
- Environmentally Sealed
- IP Rating:
- IP66
- Load Cell Cable Length:
- 20 ft
- Load Cell Other Approvals:
- cFM
- Cable Length (junction box to indicator):
- 25 ft
- Load Cell Color Code:
- Red = +Excitation, Black = -Excitation, Green = +Signal, White = -Signal
