Rice Lake RL1380-60kg Single Point Load Cell
The Rice Lake RL1380 single point load cells are constructed of stainless steel and feature an IP67 rating. The RL1830 load cells are NTEP approved for legal for trade applications.
RL1380 load cells are interchangeable with HBM PWS load cells.
Features
- 60 kg / 132.3 lb capacity rating
- Stainless steel construction
- Environmentally sealed IP67
- 2 year limited manufacturer's warranty
- NTEP Approved Class III 1:3000
- Safe overload up to 150% capacity
- 10 ft of cable
- Max platform size of 15.75 in x 15.75 in
2 year limited manufacturer's warranty
- Manufacturer:
- Rice Lake Weighing Systems
- Model:
- RL1380-60kg
- Approvals:
- FM, NTEP
- Certification:
- NTEP Certified 1:3000 Class III
- Capacity Rating:
- 60 kg / 132.3 lb
- Safe Overload:
- 150% capacity
- Length:
- 5.5"
- Height:
- 1.19"
- Width:
- 0.94"
- Thredding:
- 1/4-20 UNC
- Construction / Finish:
- Stainless steel
- Cable Color Code:
- Green = + Excitation, Black = - Excitation, Red = + Signal, White = - Signal, Yellow = Shield
- Rated Excitation:
- 5-10 VDC (15 V maximum)
- Full Scale Output:
- 2 mV/V
- Output Resistance:
- 350 (± 3) ohm
- Input Resistance:
- 350 ohm
- Insulation Resistance:
- 1,000 megohms
- Compensated Temperature Range:
- 14° F to 104° F / -10°C to 40°C
- Operating Temperature Range:
- -40° F to 150° F / -40°C to 65°C
- Seal Type:
- Environmentally sealed IP67
- Combined Error:
- 0.03 % full scale
- Cable Length:
- 10 ft
- Cable Diameter:
- 0.190 PVC jacket
- Max Platform Size:
- 15.75" x 15.75"
