MSI-9300 2000 lb Crane Scale, 2000 lb x 1 lb

Discontinued

Part #:
138705
Availability:
Typically ships in 7-10 days

MSI-9300 2000 lb Crane Scale, 2000 lb x 1 lb

The MSI-9300 series crane scale provides the rugged durability that MSI is known for, combined with wireless data processing capabilities, to give you a versatile scale for industrial hanging applications. It features a large 6 digit, 1.2 inch LED digital display with resolution settings up to 10,000 divisions for precise 0.1 percent loading accuracy. Operating times are extended up to 30 hours through a single 12-volt rechargeable battery. The electronics are shock mounted inside the robust NEMA Type 4/IP66 marine grade 356 alloy anodized cast aluminum housing.

Features

  • 2000 lb capacity rating
  • 1 lb readability
  • Safe overload up to 200% capacity
  • 6 digit, 1.2" inch LED display
  • 12V rechargeable battery with 115/230 V battery charger
  • Battery typically allows for 30 hours of operation use before charge required
  • Top lifting eye or shackle, bottom thrust bearing swivel hook
  • NEMA Type 4, IP66 marine grade 356 alloy anodized cast aluminum housing
  • Functions include power, zero, net/gross, tare and programmable test
  • Auto-off mode with selectable time limits
  • 1 year warranty

Accessories

  • RF remote controller
  • Universal direct power supply: 85-265VAC, 47-440Hz/130-300VDC
  • Crosby or equivalent top shackle for MSI-8300HT configuration
  • Heat shield for hot metal and high temperature applications
  • Substitute shackle for bottom swivel hook
  • Oversized top lifting eye or shackle
  • Oversized bottom swivel hook
  • Low headroom adapter
  • Ethernet 802.11 b/g connectivity
  • Retrofit 4300 to 9300 2450
  • Retrofit 4300 to 9300 Modem
  • Retrofit 12V 4300 to 9300 2450
  • Retrofit 12V 4300 to 9300 No Modem

Note: Contact a Scales Plus sales associate for pricing on accessories

Common Industries
  • Industrial Manufacturing
  • Steel Manufacturing
  • Commercial Fishing
  • Shipping
Documentation

MSI 9300 Series Data Sheet

1 year limited manufacturer's warranty
Capacity:
2000 lb
Readability:
1 lb
Resolution:
3,000 to 5,000 d standard (up to 10,000 d available)
Accuracy:
Ā±0.1% +1 d of applied load
Safe Overload:
200% capacity
Calibration:
Digital
Portable:
Yes
Enclosure:
NEMA Type 4, IP66 marine grade 356 alloy anodized cast aluminum
IP Rating:
IP66
Standard functions:
Power, zero, net/gross, tare and programmable test/user
Display:
6 digit, 1.2 inch LED
Dimensions:
18.3 x 13.5 x 11.65 "
Units:
Pounds, kilograms
Power:
12 volt rechargeable battery and 115/230 VAC battery charger
Operational Time:
30 hours
Operating Temperature:
-4Ā°F to 158Ā°F
Filtering:
OFF, LO, HI-1, HI-2 selectable
Manufacturer:
MSI
Model:
MSI-9300 2000 lb
