HBM S35-1000 lb Stainless Steel S-Beam Load Cell, NTEP

MSRP: $325.00
$300.00
(Save $25.00)
Part #:
64864
Availability:
Discontinued

Discontinued by the Manufacturer

HBM S35-1000 lb Stainless Steel S-Beam Load Cell, NTEP

Features

  • 1000 lb / 453.6 kg capacity rating
  • NTEP Approved 1:3000 Class III, 1:10,000 Class IIIL
  • Stainless steel construction
  • Environmentally sealed IP 67 rating
  • 3 mV/V output
  • Load cell cable length 20 ft
  • 1 year limited warranty
  • Safe overload up to 150% capacity

Common Applications

  • OEM
  • Suspended/hanging scales
  • Tension scales
1 year limited manufacturer's warranty
Manufacturer:
HBM
Model:
S35-1000 lb
NTEP:
Class III 1:3000, Class IIIL 1:10,000
Certification Number:
97-142
Approvals:
FM
Capacity:
1000 lb
Capacity:
453.6 kg
Safe Overload:
150% capacity
Length:
2"
Height:
2.4"
Width:
0.9"
Hole Threading:
1/2-20UNF
Construction:
Stainless steel
Cable Color Code:
Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Yellow = Shield
Rated Excitation:
5-10 VDC (maximum of 15 V)
Full Scale Output:
3 mV/V
Output Resistance:
350 (Ā± 3.5) ohms
Input Resistance:
430 (Ā± 60) ohms
Insulation Resistance:
10,000 megohms
Compensated Temperature Range:
14Ā‚Ā°F to 104Ā‚Ā°F (-10Ā‚Ā°C to 40Ā‚Ā°C)
Operating Temperature Range:
-40Ā‚Ā° F to 150Ā‚Ā° F / -40Ā‚Ā°C to 65Ā‚Ā°C
Seal Type:
Environmentally sealed
IP Rating:
IP67
Combined Error:
0.03 % full scale
Deflection at Capacity:
0.010 in (0.25 mm)
Cable Length:
20 ft
Cable Diameter:
0.190 polyurethane jacket
Weigh Module Available:
ITCM Isolated Tension Cell Mount
