Coti Global Sensors CG-BBS 7.5K Stainless Steel Single Ended Beam Load Cell

MSRP: $1,350.00
$1,214.52
(Save $135.48)
Part #:
CG-BBS 7.5K
Availability:
Typically ships in 1-2 days

Coti Global Sensors CG-BBS 7.5K Stainless Steel Single Ended Beam Load Cell

Features

  • 7.5K capacity rating
  • Stainless steel construction
  • IP 67 rating
  • 2 mV/V output
  • Load cell cable length 30 ft
  • Safe overload up to 150% capacity

Interchange

  • Rice Lake Weighing Systems RL40BBBS
  • Sensortronics 60007
  • BLH LBG1
  • Fairbanks 3-481XX-1, 3-486XX-1
  • HBM BBS
  • Artech 40310

Dimensional Drawing

1 year limited manufacturer's warranty
Approvals:
FM
Capacity:
7.5K
Safe Overload:
150% capacity
Length:
6.00"
Width:
1.26"
Height:
1.06"
Construction:
Stainless Steel
Cable Color Code:
Green = + Excitation, Black = - Excitation, White = + Signal, Red = - Signal
Rated Excitation:
10V AC/DC (maximum of 20 V)
Full Scale Output:
2 mV/V
Input Resistance:
800 +/- 10 ohms
Output Resistance:
750 +/- 3 ohms
Insulation Resistance:
5000 megohms
Compensated Temperature Range:
-10ļæ½C to 40ļæ½C
Operating Temperature Range:
-20ļæ½C to 60ļæ½C
Seal Type:
Environmentally Sealed
IP Rating:
IP67
Nonlinearity:
+/- 0.03% full scale
Hysteresis:
+/- 0.03% full scale
Repeatability:
+/- 0.01% full scale
Creep (30) Minutes:
+/- 0.02% full scale
Zero Balance:
+/- 1.00% full scale
Temperature Effect on Zero:
+/- 0.0027% of rated output /ļæ½C
Temperature Effect on Output:
+/- 0.0015% of applied load /ļæ½C
Cable Length:
30 ft
Part Number:
CG-BBS 7.5K
Manufacturer:
Coti Global Sensors
Model:
CG-BBS
