Discontinued by the Manufacturer
Celtron MDB-50t Double Ended Beam Load Cell
Features
- 50 ton / 100,000 lb / 45,359.2 kg capacity rating
- Alloy steel construction
- Environmentally sealed IP67 rating
- 2 mV/V output
- 700 ohm output resistance
- Load cell cable length 44.3 ft
Common Applications
- OEM
- Tank/Hopper/Silo scales
- Truck scales
1 year limited manufacturer's warranty
- Manufacturer:
- Celtron
- Model:
- MDB-50t
- Approvals:
- cFM
- Capacity Rating:
- 50 ton / 100,000 lb / 45,359.2 kg
- Length:
- 13.38"
- Width:
- 6.3"
- Construction / Finish:
- Alloy steel
- Cable Color Code:
- Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Bare = Shield
- Rated Excitation:
- 5-10 VDC (maximum of 15 V)
- Full Scale Output:
- 2 mV/V
- Output Resistance:
- 700 (± 5) ohm
- Input Resistance:
- 770 (± 10) ohm
- Operating Temperature Range:
- -40° F to 150° F / -40°C to 65°C
- Seal Type:
- Environmentally sealed IP67
- Non-linearity:
- 0.03% full scale
- Hysteresis:
- 0.03% full scale
- Insulation Resistance:
- 5000 megohms
- Cable Length:
- 44.3 ft
