Anyload 101AH-20kg S-Beam Load Cell
Features
- 20 kg / 44.1 lb capacity rating
- Alloy steel construction, nickel plated
- Environmentally sealed IP65 rating
- 2 mV/V output
- Load cell cable length 3 m
- Safe overload up to 150% capacity
Common Applications
- OEM
- Small crane scale
- Small hoppers
Documentation
1 year manufacturer's limited warranty
- Manufacturer:
- Anyload
- Model:
- 101AH-20kg
- Capacity:
- 20 kg
- Capacity:
- 44.1 lb
- Safe Overload:
- 150% capacity
- Breaking Overload:
- 300% capacity
- Rated Excitation:
- 10 VDC (maximum of 15 V)
- Height:
- 3.35"
- Width:
- 0.94"
- Hole Threading:
- M6 Depth8
- Construction:
- Alloy steel
- Finish:
- Nickle plating
- Cable Color Code:
- Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal, Bare = Shield
- Full Scale Output:
- 2 mV/V
- Output Resistance:
- 350 (+/- 3) ohms
- Input Resistance:
- 400 (+/- 20) ohms
- Compensated Temperature Range:
- 14‚° F to 122‚° F / -10‚°C to 50‚°C
- Seal Type:
- Environmentally Sealed
- IP Rating:
- IP65
- Cable Length:
- 3 m
