Features
- Aluminum construction
- Threaded holes 6-M4 Depth 10
- IP22 rating
- 1.0197mV/V+15% –0% output
- Load cell cable length 1.5 meters
- Safe overload up to 300% capacity
Documentation
1 year limited manufacturer's warranty
- Capacity:
- 3 kg
- Safe Overload:
- 300% Capacity
- Hole Threading:
- 6-M4 Depth 10
- Construction:
- Aluminum
- Cable Color Code:
- Red = + Excitation, White = - Excitation, Green = + Signal, Blue = - Signal, Yellow = Shield
- Rated Excitation:
- DC5 to 12V (maximum of 15)
- Full Scale Output:
- 1.0197mV/V+15% -0%
- Input Resistance:
- Approximately 400 ohms
- Output Resistance:
- 350±5 ohms
- Insulation Resistance:
- 500M ohms/DC50V
- Compensated Temperature Range:
- -10‚ºC to 40‚ºC
- IP Rating:
- IP22
- Cable Length:
- 1.5 meter
- Manufacturer:
- A&D Weighing
