A&D GC series counting scales offer impressive performance capabilities and user-friendly features. GC models utilize ACAI, A&D’s exclusive Automatic Count Accuracy Improvement and AIS, which instantly finds the desired piece weight. WinCT-Counting software is included, which streamlines data collection and management. With up to 1000 items stored in its onboard memory, users can quickly recall items from the library. A large variety of annunciators provide clear status updates, while color-coded keys make operation identification quick and simple.
Features
- Standard internal memory to stores up to 1,000 items
- Memory can be expanded with a MicroSD card
- Keypad for user selectable sample quantities
- AIS (Automatic Item Search) instantly finds desired piece weight
- Detachable display
- WinCT-Counting software included
- Password lock and key functions
- Automatic Counting Accuracy Improvement (ACAI)
- Dual scale capable with additional accessories
- Can be powered with mobile battery and USB (not included)
Applications
- Counting
- Weighing
- Checkweighing
Documentation
2 year manufacturer's warranty
- Capacity:
- 30 lb
- Readability:
- 0.005 lb
- Repeatability:
- +/- 0.005 lb
- Linearity:
- +/- 0.005 lb
- Units:
- lb, kg, g, oz, ozt, pcs
- Platform Size:
- 11.81" × 8.27"
- Calibration:
- External
- Communication:
- RS-232C (D-Sub 9-pin), MicroSD card*i slot, External switch input terminal
- Display Type:
- 7-segment reverse backlit LCD
- Display Digit Sizes:
- 22 mm high character, Weight: 12.5 mm high, Unit weight: 6.7 mm
- Overall Dimensions (L x W x H):
- 12.4" × 13.98" × 4.76"
- Overall Product Weight:
- Aprox. 10.8 lbs
- Power:
- AC Adapter (Included)
- Optional Power:
- USB port of another device, or off-the-shelf mobile battery*ii via USB cable (Type-A to Type-C, 1.5 m)
- Brand:
- A&D Weighing
- Model:
- GC-15K
